Yokogawa NFLC121-S00 CANopen Communication Module

In stock, ready to ship

  • Manufacturer: Yokogawa

  • Product No.: NFLC121-S00

  • Product Type: CANopen Communication Module

  • Product Origin: USA

  • Payment: T/T

  • Weight: 760g

  • Shipping port: Xiamen

  • Warranty: 12 months

Yokogawa NFLC121-S00 CANopen Communication Module

The ADV551-P63 from Yokogawa is a high-performance, 32-channel digital output module engineered for seamless integration with CENTUM VP and ProSafe-RS control systems. It utilizes current-sinking transistor outputs to efficiently control a wide range of external devices such as relays, solenoids, and indicators. A key strength of this module lies in its advanced control capabilities, supporting both pulse width modulation (PWM) and time-proportional output functions, which are essential for precise and dynamic industrial automation processes.

Core Technical Specifications

Specification Category Details
Model ADV551-P63
Manufacturer Yokogawa Electric Corporation
Product Type Digital Output Module
Number of Output Channels 32
Output Format Current sink type
Rated Applied Voltage 24 V DC
Maximum Load Current 100 mA per channel (at 26.4 V DC)
Pulse Width Output Supported
Time-Proportional Output Supported
Status Display Included
Explosion Protection Not included
Environmental Compliance ISA Standard G3
Operating Temperature –20°C to +70°C
Withstand Voltage • 2 kV AC (between output signal and system)• 500 V AC (between commons every 16 channels)
Cable Interface KS Cable Interface Adapter (Model ATD5A-00)
Redundancy Support Yes, supports dual redundant configuration
Weight 0.2 kg

Key Features and Benefits

1. Advanced Control Capabilities

  • The ADV551-P63 supports both Pulse Width Modulation (PWM) and Time-Proportional Output, giving engineers precise control over processes that require variable speed or incremental actuation, such as motor speed control or valve positioning.

  • Its 32 channels of current-sinking outputs provide ample capacity for controlling numerous devices, making it a cost-effective and space-saving solution for large-scale systems.

2. Seamless System Integration & Safety

  • Designed specifically for Yokogawa's CENTUM VP and ProSafe-RS platforms, the ADV551-P63 ensures high compatibility and reliable communication within these critical control environments.

  • The module incorporates robust electrical isolation, with a 2 kV AC withstand voltage between the output signals and the system, and 500 V AC between commons every 16 channels. This isolation protects the control system from electrical disturbances and enhances overall operational safety.

3. Enhanced Diagnostics and Rugged Design

  • An integrated status display provides immediate visual feedback on the module's operational state, simplifying system monitoring and troubleshooting.

  • Compliant with ISA Standard G3 and designed to operate in a wide temperature range from –20°C to +70°C, the ADV551-P63 delivers exceptional reliability and durability in the most demanding industrial settings.

Understanding the Model Suffix: P63

The suffix code P63 denotes specific feature sets of the module:

  • P: Indicates the module includes advanced functions: Pulse width output and time-Proportional output.

  • 6: Signifies that the module features a status display, but does not include explosion protection.

  • 3: Means the module complies with ISA Standard G3 and supports an extended operating temperature range of –20 to +70 °C.
