Yokogawa ANT502-5E Optical ESB Bus Repeater Slave Module
In stock, ready to ship
Manufacturer: Yokogawa
Product No.: ANT502-5E
Product Type: Repeater Slave Module
Product Origin: USA
Payment: T/T
Weight: 760g
Shipping port: Xiamen
Warranty: 12 months
Yes, we provide a 30-day money-back guarantee for all purchases.
Yes, all items come with a 12-month warranty from the date of shipment.
The Yokogawa ANT502-5E serves as a key component in CENTUM VP and other Yokogawa control systems. It delivers high-speed optical communication across ESB networks to support long-distance data transfer needs. This module also enhances system scalability, making it ideal for expanding industrial automation setups. Moreover, it originates from Japan, ensuring adherence to strict manufacturing quality standards.
Core Technical Specifications of ANT502-5E
|
Specification Category |
Details |
|
Model Number |
ANT502-5E |
|
Product Type |
Optical ESB Bus Repeater Slave Module |
|
Communication Type |
Optical transmission over ESB network |
|
Maximum Transmission Distance |
Up to 5 km (one hop) |
|
Power Supply |
24 V DC |
|
Power Consumption |
Less than 5 W |
|
Current Consumption |
0.5 A |
|
Operating Temperature |
−20°C to +60°C |
|
Storage Temperature |
−40°C to +85°C |
|
Dimensions |
155.9 mm × 130 mm × 32.8 mm |
|
Weight |
Approx. 0.25 kg |
|
Installation Options |
ANB11 Optical ESB Node Unit or ANT10U Repeater Unit |
|
Connector Options |
/BU1A or /HU1A (ESB connection); /BU1B or /HU1B (non-connection) |
|
Optical Connector Type |
LC (IEC61754-20 compliant) |
|
Optical Fiber Type |
Quartz single-mode optical fiber |
