Wow！Allen-Bradley 1771-ASB/E（In Box）

We are the supplier for industrial automation spare parts.We specialize in PLC module, DCS card pieces, ESD system card pieces, vibration monitoring system card pieces, steam turbine control system module, gas generator spare parts. We have established the relationship with famouse PLC DCS product maintenance service providers in the world.Our products are widely used in CNC machinery and metallurgy, oil and gas, petrochemical, chemical, paper printing, textile printing and dyeing, machinery, electronics manufacturing, automobile manufacturing, tobacco, plastic machinery, electricity, water conservancy, water treatment / environmental protection, municipal engineering, Heating, energy, transmission and distribution industries.

The Allen-Bradley 1771-ASB is a PLC 5 Universal Remote I/O Adapter Module. It interfaces with I/O modules in a 1771 I/O chassis with a Remote I/O scanner port for a processor over an I/O link. Using it instead of direct wiring reduces startup, installation, and maintenance costs by the I/O being closer to the actuators and sensors. It is compatible with 32 I/O-adapter devices via the I/O link and it uses 82 Ohm or 150 Ohm terminating resistor.The 1771-ASB module has a communication rate of 57.6 Kbps, 115 Kbps, and 230 Kbps and it weighs 1.9 pounds. It has a backplane current load of 1 A at 5 Volts DC and a maximum power dissipation of 5.2W. It requires a remote I/O adapter port for connection. For installation, it must be mounted in the left-most slot of the 1771 chassis with the I/O modules controlled by a PLC 5 processor. For wiring, the 1770-CD Belden 9463 or equivalent cable must be used. The 1771-ASB module has Active, Adapter Fault, and I/O Rack fault diagnostic Indicators, 2 switch assemblies, and a field wiring arm. It provides faster data transmission and backplane scanning up to 2500 feet at 230.4K Baud. It supports serial communication and reads/writes data in parallel form. It supports 4, 8, 12, 16, or 32-slot I/O chassis and 1 and 2-slot I/O addressing. The 1771-ASB improves scan time and I/O image space savings by scanning all slots except the last 4. It eases troubleshooting with its enhanced diagnostics features.The 1771-ASB is an Allen-Bradley hardware that belongs to the PLC 5 product family of Programmable Logic Controllers (PLC). This electronic hardware is a remote I/O adapter that is used to interface the to Remote I/O (RIO) network. In actual, this RIO adapter responds to the request of the Remote I/O (RIO) scanner in the network. This adapter supports transmission of data at cable length and speeds of 10,000 feet at 57.6K baud, faster backplane scanning and data transmission up 2500 feet at 230.4K baud.RIO Communication is physically implemented following daisy-chain topology. In this topology, the start and end points must be installed with a terminating resistor to close the network segment. The same is true for this protocol, either an 82 Ohm or 150 Ohm resistor may be used to terminate the segment. 150 Ohm is used for older configuration while 82 Ohms is used in enhanced RIO network versions. Belden 9463 or more popularly known as Belden Blue Hose cable is used for Remote I/O protocol.This module is provided with status indicators such as ACTIVE, ADAPTER FAULT, and I/O RACK FAULT. For the Active status, the LED light should be Green to indicate normal operation. When an adapter fault is experienced, Red light illuminates while for Rack Fault, RED led activates.This module receives/sends data from/to the I/O scanner in serial form, reads/writes data from/to the input modules in parallel form, reads/writes data from/to the output modules in parallel form. Configuration software used with this module are RSLinx and RSLogix 5 programming software.The 1771-OMD PLC 5 Digital Output Module by Allen-Bradley is a fused output module installed in a single slot of the 1771 I/O chassis. The module has 16 outputs with an output voltage range between 184 and 250V AC at 47 - 63Hz and an output current of 2A for each output and an aggregate current that must exceed 8A for the entire module. The module has a surge current of 25A which flows on each output for 100ms and keeps recurring every 1 second and 25A on the entire module for 100ms that is repeatable every 1 second. The 1771-OMD requires 10mA per output at 220V AC (60Hz) minimum current load to remain ON and the maximum voltage loss in the ON state is 1.5V at 2A. It has 4mA per output at 220V AC OFF state leakage current and the maximum signal delay time on the outputs is 10ms for ON and 8.3 to 9.1ms for OFF at 60Hz. The 1771-OMD has a minimum power dissipation of 3.7 Watts which maxes at 17.3 Watts when operational and the maximum operational thermal dissipation is 59 BTU/hr. It draws a backplane current of 700mA at 5V DC (+5%) and offers circuit voltage isolation which meets or exceeds UL and CSA standards. The 1771-OMD requires a standard field wiring arm or an optional fused wiring arm with a wiring screw torque of 7 - 9 inch pounds and all outputs are fused with 10A 250V rectifier fuse (1/4 x 1-1/4 inch). It has a working temperature bracket between 0 and 60 0C (32 and 140 0F) around a 5-95% humidity condition without condensation and it has a designated -40-85 0C (-40-185 0F) storage temperature range.
