TSX 16ch RTD Input Module TSXAEM1613 Schneider Pt100
In stock, ready to ship
Manufacturer: Schneider
Product No.: TSXAEM1613
Product Type: Analog Input Module (RTD)
Product Origin: USA
Payment: T/T
Weight: 1600g
Shipping port: Xiamen
Warranty: 12 months
Yes, we provide a 30-day money-back guarantee for all purchases.
Yes, all items come with a 12-month warranty from the date of shipment.
Product Overview
Schneider TSXAEM1613 is a 16-channel RTD analog input module for Modicon TSX Series 7 / Premium platforms. It accepts 3-wire Pt100 sensors for precise temperature measurement across a wide industrial range.
Key Specs
- Channels: 16 RTD inputs
- Sensor type: Pt100 3-wire
- Resolution: 13-bit / 0.1 °C typical
- Measurement range: –200 °C to +600 °C (sensor dependent)
- Platform: Modicon TSX Series 7 / Premium
- Diagnostics: Open/short circuit detection
Why Choose This
- High-density temperature input for legacy TSX systems
- Dedicated Pt100 support with good accuracy
- Channel diagnostics for reliable operation
- Direct rack mounting in TSX architecture
Common Questions
- Sensor type? Pt100 3-wire RTD.
- How many channels? 16.
- Platform? Modicon TSX Series 7 / Premium.
Mounting Steps
- Install the module in a compatible TSX rack slot.
- Wire 3-wire Pt100 sensors observing correct polarity and shielding.
- Configure channels in PL7 or Unity Pro software.
- Power up and verify input status and diagnostics.
- Calibrate or scale values as required by the application.
Buying Advice
- Confirm Pt100 3-wire sensor compatibility.
- Useful spare for maintaining existing TSX temperature loops.
- Check overall system power budget before adding multiple modules.
