Triconex
Triconex 8110N2 Digital Output Module
In stock, ready to ship
Manufacturer: Triconex
Product No.: 8110N2
Product Type: Digital Output Module
Product Origin: USA
Payment: T/T
Weight: 1g
Shipping port: Xiamen
Warranty: 12 months
Yes, we provide a 30-day money-back guarantee for all purchases.
Yes, all items come with a 12-month warranty from the date of shipment.
The TRICONEX 8110N2 is a digital output module designed for use in Triconex safety and critical control systems. It provides reliable and fault-tolerant switching for field devices such as solenoids, relays, and indicators. Engineered for Safety Instrumented Systems (SIS) with SIL3 compliance, this module ensures continuous and secure operation in demanding industrial environments.
Technical Specifications
-
Output Type: Digital (discrete) outputs
-
Number of Channels: 32 isolated output channels
-
Output Signal Type: 24 V DC nominal
-
Output Current Capacity: 0.5 A per channel maximum
-
Isolation: 2500 V RMS channel-to-backplane isolation
-
Response Time: Less than 10 ms
-
Redundancy: Compatible with Triple Modular Redundancy (TMR) architecture
-
Diagnostics: Per-channel status monitoring and fault detection
-
Operating Temperature: 0°C to +60°C
-
Storage Temperature: −40°C to +85°C
-
Power Consumption: 8 W typical
-
Dimensions (H × W × D): 266 mm × 32 mm × 195 mm
-
Weight: 0.8 kg
-
Compliance: IEC 61508 SIL3, TÜV-certified
-
Mounting: Installs into standard Tricon I/O chassis slots
