Schneider TSXDSY32T2K Discrete Output Module
In stock, ready to ship
Manufacturer: Schneider
Product No.: TSXDSY32T2K
Product Type: Discrete output module
Product Origin: USA
Payment: T/T
Weight: 760g
Shipping port: Xiamen
Warranty: 12 months
Yes, we provide a 30-day money-back guarantee for all purchases.
Yes, all items come with a 12-month warranty from the date of shipment.
The TSXDSY32T2K by Schneider Electric is a discrete output module for the Modicon Premium automation platform. It offers 32 solid-state protected outputs operating at 24 V DC. Each channel supports up to 0.1 A with a total maximum module current of 3.2 A. This module includes built-in protections for overload, short-circuits, and reverse polarity, ensuring reliable and safe operation.
Key Technical Specifications
| Specification | Details |
|---|---|
| Product Type | Discrete Output Module |
| Output Channels | 32 solid-state protected outputs |
| Output Voltage | 24 V DC positive (19–30 V), EN/IEC 61131-2 compliant |
| Current per Channel | 0.1 A |
| Max Current per Module | 3.2 A |
| Maximum Leakage Current | 0.1 mA at 30 V |
| Max Tungsten Load | 1.2 W |
| Residual Voltage [Ures] | 1.5 V |
| Response Time | 1.2 ms |
| Output Paralleling | Up to 3 outputs |
| Overvoltage Protection | Transil diode |
| Reverse Polarity Protection | Reverse mounted diode |
| Overload Protection | Automatic trip |
| Short-circuit Protection | Automatic trip |
| Minimum Load Impedance | 220 Ω at logic 1 state |
| Isolation Resistance | > 10 MΩ at 500 V DC |
| Power Dissipation | 1.6 W + 0.1 W × number of outputs used |
| Electrical Connection | 2 × HE-10 connectors |
| Current Consumption | 140 mA at 5 V DC |
| Module Format | Standard |
| Net Weight | 0.3 kg |
| Marking & Certification | CE |
Environmental & Compliance Data
-
Operating Temperature: 0 to 60 °C
-
Storage Temperature: -25 to 70 °C
-
Relative Humidity (Operation): 10–95% (non-condensing)
-
Relative Humidity (Storage): 5–95% (non-condensing)
-
Operating Altitude: 0–2000 m
-
Protection Class: IP20
-
Pollution Degree: 2
-
Protective Treatment: TC treatment
-
Dielectric Strength: 1500 V AC, 50/60 Hz, 60 seconds
-
Standards Compliance:
-
IEC 61131-2
-
UL 508
-
CSA C22.2 No 142 and No 213 (Class I Division 2 Groups A-D)
-
73/23/EEC, 89/336/EEC, 92/31/EEC, 93/68/EEC
-
Certifications: ABS, RINA, GL, DNV, RMRS, LR, BV
Packaging & Shipping Details
| Package Detail | Specification |
|---|---|
| Unit Type | PCE (Single unit) |
| Package Dimensions | 26 × 18 × 5.5 cm (L × W × H) |
| Package Weight | 417 g |
| Returnability | No |
| Country of Origin | France |
