Schneider | TSXAEY800 | Premium 8ch Analog Input 12-bit
Manufacturer: Schneider
Product No.: TSXAEY800
Product Type: Analog Input Module
Product Origin: USA
Payment: T/T
Weight: 1800g
Shipping port: Xiamen
Warranty: 12 months
Yes, we provide a 30-day money-back guarantee for all purchases.
Yes, all items come with a 12-month warranty from the date of shipment.
Product Overview
Schneider Electric TSXAEY800 is an 8-channel high-level analog input module for the Modicon Premium platform. It accepts voltage and current signals with common-point reference and 12-bit conversion for process measurement applications.
Key Specs
- Platform: Modicon Premium
- Channels: 8 high-level analog inputs (common point)
- Input types: 0–20 mA, 4–20 mA, ±10 V, 0–10 V, 0–5 V, 1–5 V
- Conversion: 12 bits
- Read cycle: Nominal 27 ms; fast cycle available
- Current consumption: Approx. 270 mA at 5 V DC
- Format: Standard module
Why Choose This
- Multi-range voltage and current inputs in one module
- Suitable for transmitters and process sensors
- Standard Premium form factor
- Direct replacement for existing TSXAEY800 positions
Common Questions
- Channels? 8 high-level with common point.
- Resolution? 12-bit conversion.
- Platform? Modicon Premium.
Mounting Steps
- Install the module in a Premium rack slot.
- Wire field signals observing common-point and polarity rules.
- Configure channel ranges in the programming software.
- Power up and verify channel values and diagnostics.
- Validate process readings under operating conditions.
Buying Advice
- Note: Commercial status discontinued; X80 BMXAMI0810 is a typical migration path for new designs.
- Confirm input range and common-point wiring match the installation.
- Useful spare for existing Premium analog input positions.
