Schneider | BMXXTSHSC20 | Connector Kit for Counter Module
Manufacturer: Schneider
Product No.: BMXXTSHSC20
Product Type: Connector Kit
Product Origin: USA
Payment: T/T
Weight: 1300g
Shipping port: Xiamen
Warranty: 12 months
Yes, we provide a 30-day money-back guarantee for all purchases.
Yes, all items come with a 12-month warranty from the date of shipment.
Product Overview
Schneider Electric BMXXTSHSC20 is a connector kit for Modicon X80 / M340 counter modules. It includes two 16-pin connectors and one 10-pin connector for field wiring of high-speed counter interfaces such as BMXEHC0200.
Key Specs
- Type: Connector kit
- Contents: 2× 16-pin + 1× 10-pin connectors
- Compatibility: BMXEHC0200 and related counter modules
- Platform: Modicon X80 / M340
- Application: High-speed counter field wiring
Why Choose This
- Matched connectors for X80 counter modules
- Enables correct termination of encoder and pulse inputs
- Standard accessory for BMXEHC series
- Simplifies module installation and replacement
Common Questions
- Contents? 2× 16-pin + 1× 10-pin connectors.
- Use? Counter modules such as BMXEHC0200.
- Platform? Modicon X80 / M340.
Mounting Steps
- Select the connectors matching the counter module pinout.
- Wire encoder, pulse and supply signals to the connectors.
- Plug the connectors onto the module until fully seated.
- Secure strain relief and verify polarity.
- Power up and test counter operation.
Buying Advice
- Required accessory when ordering X80 high-speed counter modules.
- Keep spares for rapid module exchange.
- Confirm exact module model before ordering.
