Rockwell Allen-Bradley 2711P-RDK15C 15-Inch Color Display Module
In stock, ready to ship
Manufacturer: Allen-Bradley
Product No.: 2711P-RDK15C
Product Type: Display Module
Product Origin: USA
Payment: T/T
Weight: 500g
Shipping port: Xiamen
Warranty: 12 months
Yes, we provide a 30-day money-back guarantee for all purchases.
Yes, all items come with a 12-month warranty from the date of shipment.
Overview
The Rockwell Automation 2711P-RDK15C is a 15-inch color display module designed for use with the PanelView Plus 6 and PanelView Plus 7 operator interface terminals. It features a high-resolution TFT LCD touchscreen and serves as a replacement or upgrade component for compatible PanelView Plus logic modules. This unit supports visualization of HMI applications developed in FactoryTalk View ME and is intended for industrial environments requiring large-format operator displays.
Technical Specifications
- Manufacturer: Rockwell Automation
- Catalog Number: 2711P-RDK15C
- Product Type: Display Module (Color Touchscreen)
- Display Size: 15 inches
- Display Type: TFT active matrix LCD
- Resolution: 1024 × 768 pixels (XGA)
- Touchscreen Type: Analog resistive
- Backlight: LED, rated for 50,000 hours
- Input Voltage: 24 VDC nominal
- Power Consumption: 39 W typical, 70 W max (2.9 A @ 24 VDC)
- Vibration Tolerance: 10–57 Hz @ 0.012 in. displacement, 57–500 Hz @ 2 G
- Compatible Logic Modules: PanelView Plus 6/7 logic modules
Dimensions and Weight
- Width: 390 mm
- Height: 290 mm
- Depth: 60 mm
- Net Weight: 3.5 kg
- Mounting Type: Panel-mounted
- Cooling Method: Passive (natural convection)
