Redundant Power Supply BMXCPS4022 Schneider X80 24-48VDC
Manufacturer: Schneider
Product No.: BMXCPS4022
Product Type: Power Supply Module
Product Origin: USA
Payment: T/T
Weight: 1900g
Shipping port: Xiamen
Warranty: 12 months
Yes, we provide a 30-day money-back guarantee for all purchases.
Yes, all items come with a 12-month warranty from the date of shipment.
Product Overview
Schneider Electric BMXCPS4022 is a redundant (Hot Standby capable) power supply module for Modicon X80. It accepts 24–48 V DC primary and provides 3.3 V logic and 24 V I/O power for processors and modules, supporting redundant configurations.
Key Specs
- Platform: Modicon X80
- Type: Redundant power supply module
- Primary: 24–48 V DC (18–62.4 V limits)
- Secondary: 18 W at 3.3 V DC; 40 W at 24 V DC class
- Current: Approx. 5.5 A at 3.3 V; 1.67 A at 24 V
- Diagnostics: Redundancy status, temperature, lifetime via network
- Protection: Overload, overvoltage, short-circuit on secondary
- Compatibility: All X80 backplanes; M340 / M580
Why Choose This
- Supports Hot Standby / redundant power architectures
- Wide 24–48 V DC primary for flexible plant power
- Advanced diagnostics including remaining lifetime
- Direct replacement for Quantum-era 140CPS power supplies
Common Questions
- Primary? 24–48 V DC.
- Redundant? Yes, HSBY capable.
- Platform? Modicon X80.
Mounting Steps
- Install the module in the X80 rack power supply slot.
- Connect 24–48 V DC primary with correct fusing and polarity.
- For redundancy, install the second BMXCPS4022 and interconnect as specified.
- Power up and verify OK and redundancy status LEDs.
- Confirm secondary voltages before loading I/O modules.
Buying Advice
- Calculate total 3.3 V and 24 V load before selecting capacity.
- Use matched pairs for redundant power systems.
- Critical spare for X80 redundant power supply positions.
