ABB NIAI04 Analog Input Termination Module

Reliable Interface for Analog Signal Acquisition in INFI 90 DCS

Product Overview

The NIAI04 is an Analog Input Termination Module designed for ABB’s Bailey INFI 90 Distributed Control System (DCS). It provides the physical interface between analog field signals and analog slave modules such as IMASI02 or IMASM01, enabling accurate and reliable signal acquisition for process control applications.

Technical Specifications

Attribute Specification
Model NIAI04
System Compatibility Bailey INFI 90 DCS
Number of Channels 16 analog input channels
Input Signal Range Configurable for 4–20 mA or 0–10 VDC
Resolution 12-bit analog-to-digital conversion
Input Impedance High impedance for minimal signal loading
Power Supply Voltage +5 VDC ±5%
Current Consumption Approx. 300 mA
Operating Temperature 0°C to +60°C
Humidity Range 0% to 95% RH, non-condensing
Dimensions (W × H × D) 17.8 × 5.1 × 17.8 cm
Weight 0.3 kg
Mounting Panel or rack-mounted
Certifications CE, RoHS

Features

  • Interfaces with IMASI02 and IMASM01 analog slave modules
  • Supports two-wire transmitter connections for field instrumentation
  • Provides channel-level configuration for signal type and range
  • Ensures real-time analog data acquisition with high accuracy
  • Compact design for industrial control panels and DCS racks
  • Designed for critical process environments with robust electrical isolation
