New Foxboro H90 Workstation Server

New Foxboro H90 Workstation Server

Foxboro H90

overview

As a multipurpose server running the Windows Server 2008 R2 operating system, the Model H90 server supports:

• Hosting Foxboro Evo™ Control Core Services (Control Core Services) or Foxboro Evo Control Software (the Control Software) workstations.

• Data acquisition and processing related to a broad range of applications.

• File serving capabilities.

• Display of graphics and text.

• Interface with corporate communication networks.

Feature

Operating System:

• Windows Server 2008 Release 2 (R2)

Hardware Features:

• High-end processor speed

• 8 GB base memory

• Up to eight internal Redundant Array of Independent Disks (RAID) with optional hot swap spare drives

• Redundant hot-swap power supplies

Functionalities:

• Hosts control stations

• Supports data acquisition and monitoring functions

• Serves as a platform for Control Core Services software or Control Software applications

• Acts as a human interface station

Networking Capabilities:

• Supports viewing Control Core Services software or Control Software applications from remote client stations over local area networks (LANs)

Specifications

Dimensions and Weight

Keyboard

• Height: 35 mm (1.4 in)

• Width: 445 mm (17.5 in)

• Depth: 150 mm (5.9 in)

• Weight: 1.8 kg (4.0 lbs)

Chassis

• Maximum outside dimensions with bezel and feet

  • Height: 87.3 mm (3.44 in) with bezel

  • Width: 445 mm (17.5 in)

  • Depth: 680 mm (26.75 in)

• Rack Weight: 23.6 kg (51.5 lbs) maximum configuration

Functional Specifications

Memory:

• 8GB DDR4 Registered Memory

Devices:

• SAS Peripherals:

  • 1 internal system disk drive, up to 8 optional internal expansion disk drives

• Controller Peripherals:

  • 1 SATA CD-RW/DVD drive

Video Displays (Up to 4):

• 23-inch LCD USB Touchscreen Monitor

• 23-inch LCD Monitor

• 40-inch LCD Overview Monitor

Interfaces to External Devices:

• USB:

  • Mouse or optional trackball

  • Alphanumeric keyboard

  • Up to 4 USB annunciator keyboards (via optional hub)

  • Up to 4 optional touchscreens

• Audio:

  • Audio speakers

• Serial Interface Port:

  • RS-232-C compatible

• Ethernet Interface Communications:

  • PCIe Ethernet network interface cards (10/100Base-TX or 100Base-FX)

  • Four integrated Ethernet ports (10/100/1000Base-T)

Power Supplies:

• 2 redundant, hot-swap, 800W auto-switching input power supplies

Power Requirements:

• Input power: 100-240V AC, 50-60 Hz

• Inrush current: 30A power supply for 20 ms

Cooling:

• Hot swappable, redundant I/O and processor fans

Video Output:

• Dual head DisplayPort/DVI PCIe video card (up to 1600 x 1200 resolution)

• Quad-head, analog-only PCIe video card assembly

• Remote Graphics Unit (optional)

Screen Presentation:

• Refresh rate: Up to 85 Hz

• Colors: 32 bit

• Resolution:

  • Standard (4:3): Up to 1600x1200 pixels

  • Widescreen (16:9): Up to 1920x1080 pixels
