In Stock Schneider Modicon 140NOA62200 Interbus Master Module
In stock, ready to ship
Manufacturer: Schneider
Product No.: 140NOA62200
Product Type: Master Module
Product Origin: France
Payment: T/T
Weight: 900g
Shipping port: Xiamen
Warranty: 12 months
Yes, we provide a 30-day money-back guarantee for all purchases.
Yes, all items come with a 12-month warranty from the date of shipment.
Overview
The 140NOA62200 is a Generation 4 Interbus Master Module designed for the Modicon Quantum automation platform. It enables communication between Quantum CPUs and Interbus-compatible devices using the PCP V2.0 protocol. This module supports RS485 isolated serial communication at 500 kbit/s and is suitable for standard industrial applications requiring distributed I/O control.
Technical Specifications
| Manufacturer | Schneider Electric |
| Brand | Modicon Quantum |
| Catalog Number | 140NOA62200 |
| Product Type | Interbus Master Module |
| Communication Protocol | Interbus RS485 (isolated, 500 kbit/s) |
| Protocol Standard | DIN 66020 |
| Module Profile | PCP V2.0 |
| Software Compatibility | Concept, ProWORX 32 (V2.5 SR2) |
| Compatible CPUs | 140CPU11303 (6 racks), 140CPU43412A/53414B (2 racks) |
| Cable Type | Twisted pair |
| Maximum Cable Length | ≤20 m |
| Memory Architecture | 128 kB + 256 kB firmware EPROM, 2 kB dual-port RAM, 256 kB + 32 kB data RAM, 64 kB EEPROM, 64 kB multi-port RAM |
| Bus Current Requirement | 800 mA |
| Power Dissipation | 4 W |
| Electrical Connection | Dual SUB-D 9 connectors (Interbus link) |
| Local Signaling | 3 green LEDs (ACTIVE, RUN, IS-B RUN), 8 red LEDs (faults), 1 yellow LED (bus segment shutdown) |
| EMC Compliance | IEC 801-2 (ESD), IEC 801-3 (radiated immunity) |
| ESD Protection | 4 kV contact, 8 kV air discharge |
| Radiated Immunity | 10 V/m (80–1000 MHz) |
| Operating Temperature | 0 to 60 °C |
| Storage Temperature | –40 to 85 °C |
| Relative Humidity | 95% non-condensing |
| Altitude Rating | ≤5000 m |
| Certifications | UL, CSA |
Dimensions and Weight
| Module Format | Standard Quantum slot size |
| Mounting Type | Quantum rack-mounted |
| Net Weight | 0.9 kg |
| Cooling Method | Passive (natural convection) |
