IC694MDL916 | Emerson GE Isolated Relay Output Module

In stock, ready to ship

  • Manufacturer: GE Fanuc

  • Product No.: IC694MDL916

  • Product Type: Relay Output

  • Product Origin: USA

  • Payment: T/T

  • Weight: 300g

  • Shipping port: Xiamen

  • Warranty: 12 months

IC694MDL916 | Emerson GE Isolated Relay Output Module

GE IC694MDL916 | 16-Point Isolated Relay Output Module

The IC694MDL916 is a 16-point isolated relay output module designed for controlling a wide range of AC and DC loads in industrial automation systems. Each output uses a Form A (normally open) relay, making it ideal for applications requiring electrical isolation and high current switching.

Technical Specifications

Attribute Details
Series PACSystems RX3i
Output Channels 16 Form A relays (isolated)
Output Voltage Range 5–125 VDC, 5–250 VAC
Output Current Up to 4 A per point
Frequency 50/60 Hz (AC only)
Isolation Galvanic isolation per channel
Power Consumption 300 mA from 5V bus, 150 mA from 24V relay supply
Mounting RX3i rack (any I/O slot)
Dimensions 34 × 145 × 140 mm
Operating Temp 0°C to +60°C
Certifications UL, CE, ATEX, Zone 2, HAZLOC
Terminal Block Required High-density (IC694TBBx32 or IC694TBSx32)

Key Features

  • High Current Switching: Handles up to 4 A per output—great for motors, solenoids, and lamps
  • Electrical Isolation: Each relay is isolated for enhanced safety and noise immunity
  • Flexible Voltage Support: Works with both AC and DC loads across a wide voltage range
  • Hot-Swappable: Can be replaced without shutting down the system
  • Diagnostic LEDs: Visual indicators for output status and module health
  • Software Configurable: Easily set up using Proficy Machine Edition or Service Pack 2+
