GE Fanuc

IC670MDL930 | GE Fanuc | Field Control Relay Output Module

In stock, ready to ship

  • Manufacturer: GE Fanuc

  • Product No.: IC670MDL930

  • Product Type: Relay Output

  • Product Origin: USA

  • Payment: T/T

  • Weight: 1000g

  • Shipping port: Xiamen

  • Warranty: 12 months

IC670MDL930 | GE Fanuc | Field Control Relay Output Module

GE Fanuc IC670MDL930 | 16-Point Isolated Relay Output Module

The IC670MDL930 is a 16-point isolated relay output module from the GE Fanuc Series 90-70 system. Designed for reliable switching of AC and DC loads, it features Form A (normally open) relays with galvanic isolation per channel for enhanced safety and noise immunity.

Technical Specifications

Attribute Details
Series GE Fanuc Series 90-70
Output Channels 16 isolated Form A relays (normally open)
Output Voltage Range 5–125 VDC, 5–250 VAC
Output Current Up to 4 A per point
Frequency 50/60 Hz (AC only)
Isolation Galvanic isolation per channel
Power Consumption 300 mA from 5V bus, 150 mA from 24V relay supply
Mounting Series 90-70 rack (any I/O slot)
Dimensions Approx. 213 × 165 × 50 mm (8.4" × 6.5" × 2")
Operating Temperature 0°C to +60°C
Certifications UL, CE
Terminal Block Requires external terminal block (e.g., IC697MDL932)

Key Features

  • 16 isolated relay outputs for safe and reliable load switching
  • Wide voltage and current range supports diverse load types
  • Galvanic isolation reduces interference and improves noise immunity
  • Compatible with Series 90-70 racks and modular architecture
  • Diagnostic LEDs for output status monitoring
  • Designed for industrial environments with robust construction
