Honeywell
Honeywell 2MLQ-TR4B Transistor Output Module 32-Point
In stock, ready to ship
Manufacturer: Honeywell
Product No.: 2MLQ-TR4B
Product Type: Transistor Output
Product Origin: USA
Payment: T/T
Weight: 260g
Shipping port: Xiamen
Warranty: 12 months
Yes, we provide a 30-day money-back guarantee for all purchases.
Yes, all items come with a 12-month warranty from the date of shipment.
Honeywell 2MLQ-TR4B
32-Point Transistor Digital Output Module (Source Type) for MasterLogic-200 PLC
Product Description
The Honeywell 2MLQ-TR4B is a 32-point transistor digital output module designed for the MasterLogic-200 PLC system. It features source-type transistor outputs with photo-coupler isolation, ensuring reliable signal transmission for industrial automation tasks. This module is ideal for driving low-power devices such as relays, indicators, and solenoids.
- Manufacturer: Honeywell
- Catalog Number: 2MLQ-TR4B
- Type: Digital Output Module
- Certifications: CE
Technical Specifications
| Attribute | Specification |
|---|---|
| Product Type | Digital Output Module |
| Output Type | Transistor (Source Type) |
| Number of Channels | 32 points |
| Rated Load Voltage | DC 12V / 24V |
| Load Voltage Range | DC 10.2V – 26.4V |
| Max Load Current | 0.1 A per point, 2 A per COM |
| Surge Absorber | Zener diode |
| Response Time | 1 ms (On ↔ Off) |
| Isolation Method | Photo-coupler isolation |
| External Connection | 40-pin connector |
| Current Consumption | 130 mA (all points ON) |
| Operating Temperature | 0°C to +55°C |
| Storage Temperature | −25°C to +70°C |
| Humidity Range | 5% to 95% RH (non-condensing) |
| Dimensions (W × H × D) | 170 × 98 × 19 mm |
| Weight | 0.26 kg |
Features
- 32-channel source-type transistor outputs
- Fast 1 ms switching for responsive control
- Photo-coupler isolation for signal integrity
- Compact form factor for dense I/O configurations
- Zener diode surge protection
- Compatible with MasterLogic-200 PLC architecture
- Suitable for driving solid-state relays, lamps, and actuators
