GE Fanuc Field Control Discrete Output Model: IC670MDL730

In stock, ready to ship

  • Manufacturer: GE Fanuc

  • Product No.: IC670MDL730

  • Product Type: Discrete Output

  • Product Origin: USA

  • Payment: T/T

  • Weight: 800g

  • Shipping port: Xiamen

  • Warranty: 12 months

GE Fanuc Field Control Discrete Output Model: IC670MDL730

Overview

The IC670MDL730 is a 24 VDC Positive Logic Discrete Output Module designed for use in GE Field Control systems. It provides 8 electronically protected output channels, each capable of sourcing up to 2.0 A, with built-in short-circuit and overcurrent protection. This module is ideal for controlling solenoids, relays, and pilot lights in distributed I/O architectures, especially in environments requiring high reliability and fault tolerance.

Technical Specifications

Manufacturer GE Fanuc (now Emerson Automation)
Catalog Number IC670MDL730
Product Type Discrete Output Module
Output Type 24 VDC Positive Logic (Source)
Number of Output Points 8
Max Current per Point 2.0 A
Max Total Module Current 8.0 A
Protection Features Electronic short-circuit and overcurrent protection
Fault Detection Per-point fault indication via yellow LEDs
Output Status Indication Per-point green LEDs
Power Supply External 24 VDC for load; internal via Bus Interface Unit
Isolation Opto-isolated outputs
Compatible Bus Interface Units Genius (IC670GBI002 Rev 2.10+), Profibus, Interbus-S
Data Format 8 bits (1 byte) discrete output
Communication Rate Up to 153.6 kbaud (adaptive)
Operating Temperature Range 0 to 60 °C (some sources suggest -20 to +70 °C)
Mounting Type Field Control rack or DIN rail
Certifications CE, UL, CSA; suitable for Class 1, Div 2 areas

Dimensions and Weight

Module Width 160 mm
Module Height 160 mm
Module Depth 120 mm
Weight 0.8 kg
Slot Occupancy 2 slots

Key Features

  • 8 electronically protected outputs with up to 2.0 A sourcing capability per channel
  • Built-in electronic short-circuit and overcurrent protection
  • Per-point fault detection via yellow LEDs
  • Output status indication via green LEDs
  • Opto-isolated outputs for noise immunity and reliability
  • Compatible with Genius, Profibus, and Interbus-S bus interface units
  • Hot-swappable design for minimized downtime
  • Certified for CE, UL, and CSA; suitable for Class 1, Division 2 environments

Product Questions

Q: What type of loads can the IC670MDL730 drive?
It can drive solenoids, relays, pilot lights, and other DC-powered devices up to 2.0 A per channel.

Q: How does fault protection work?
Each output channel includes electronic short-circuit and overcurrent protection. Faults are indicated via yellow LEDs and can be diagnosed via GE CIMPLICITY or similar software.

Q: Is the module hot-swappable?
Yes. It supports replacement without powering down the system, minimizing downtime.

Q: What network topologies are supported?
It supports bus, star, and daisy-chain topologies with Genius or other compatible bus interfaces.

Q: Is it suitable for hazardous environments?
Yes, when paired with appropriate enclosures, it meets Class 1, Division 2 requirements for Zone 2 applications.
