Foxboro 900701-10-02 Fast Ethernet Switch Module

The Foxboro 900701-10-02 is a high-performance Fast Ethernet switch module designed for industrial and automation networking applications. Equipped with 48 RJ45 ports and Power over Ethernet (PoE) capability, it enables robust, high-density connectivity across complex network topologies.

Ideal for distributed control systems and large-scale automation environments, this module supports flexible network scaling with stacking capability for up to 8 switches, dual uplink ports, and full standards compliance for seamless integration. Its versatile management interfaces allow for intuitive monitoring and configuration through WebView GUI, CLI, or SNMP protocols.

Key Features

• 48 × 10/100 Mbps RJ45 Ethernet ports

• 2 × 1000BASE-T stacking ports (Ports 49 & 50)

• 2 × SFP uplink ports (Ports 51 & 52)

• PoE Support:

• IEEE 802.3af compliant

• Up to 15.4 W per port

• Total PoE budget: 360 W

• Stacking Capability: Supports stacking of up to 8 A2 switches

• Flexible Management Options:

• WebView GUI

• Command Line Interface (CLI)

• SNMP

Technical Specifications

• Model: 900701-10-02

• Ethernet Ports: 48 × 10/100 Mbps RJ45

• Uplink Slots: 2 × SFP (Ports 51 & 52)

• Stacking Ports: 2 × 1000BASE-T RJ45 (Ports 49 & 50)

• Supported Uplink Modules: MGBIC-LC01, LC03, LC09, MT01

• Power Supply:

• Internal power supply

• Redundant option supported via C2RPS-POE

• Power over Ethernet (PoE):

• IEEE 802.3af compliant

• Maximum 15.4 W per port

• Total PoE budget: 360 W

• Standards Compliance:

• IEEE 802.3 (10BASE-T)

• IEEE 802.3u (Fast Ethernet)

• IEEE 802.3ab (Gigabit Ethernet)

• IEEE 802.3z (Gigabit Fiber)

• IEEE 802.3ad (Link Aggregation)

• IEEE 802.3af (PoE)
