Ethernet Module TSXETY110 Telemecanique Schneider

Product Overview

The Schneider Electric Telemecanique TSXETY110 is a dedicated Ethernet TCP/IP communication module for the Modicon Premium PLC platform. It provides reliable industrial networking via Modbus TCP and Ethway/X-Way protocols for seamless supervisory data exchange.

Key Specs

• Series: Modicon Premium
• Physical Interfaces: 1x RJ45 (10BASE-T) and 1x AUI (100BASE-5)
• Transmission Rate: 10 Mbit/s
• Supported Protocols: Modbus TCP messaging, Uni-TE, Ethway/X-Way, SNMP
• Current Consumption: 800 mA at 5 VDC (RJ45 mode) / 1200 mA at 5 VDC (AUI mode)
• Module Format: Standard single slot

Why Choose This

• Flexible Connectivity: Supports both RJ45 twisted-pair and traditional AUI physical interfaces on a single card.
• Multi-Protocol Support: Seamlessly bridges legacy Ethway networks with modern Modbus TCP/IP industrial networks.
• Diagnostic LEDs: Integrated front panel status indicators provide real-time network collision, run, and error diagnostics.

Common Questions

• Q: Which programming environment supports the TSXETY110? A: This module is fully supported by PL7 Pro programming software.
• Q: Can it be hot-swapped during rack operation? A: Always power down the local rack segment before inserting or removing communication modules.

Mounting Steps

1. Isolate power to the Modicon Premium rack to prevent electrical electrical faults.
2. Carefully align the module edge connectors with the designated rack slot guides.
3. Push the module inward until the rear connectors seat completely into the backplane.
4. Secure the top locking screw and attach the RJ45 or AUI network cable.

Buying Advice

• Check total 5V backplane power consumption to ensure your rack power supply has adequate current margin.
• Confirm whether your network topology uses RJ45 twisted pair or AUI drop cables before purchasing jumpers.
