Epro
Emerson EPRO PR6424/013-030 + CON021 Eddy Current System
In stock, ready to ship
Manufacturer: Epro
Product No.: CON021+PR6424/013-030
Product Type: Eddy Current System
Product Origin: Germany
Payment: T/T
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
Yes, we provide a 30-day money-back guarantee for all purchases.
Yes, all items come with a 12-month warranty from the date of shipment.
Product Overview
Emerson PR6424/013-030 is a 16mm non-contact eddy current sensor paired with the CON021 Signal Converter. It provides precise radial and axial shaft displacement measurement for turbines, compressors, and pumps. With high linearity, stainless steel housing, and API 670 compliance, it ensures reliable vibration and position monitoring in harsh industrial environments.
Specification
Dynamic Performance |
|
|---|---|
| Sensitivity / Linearity | 4 V/mm (101.6 mV/mil) ≤ ±1.5% |
| Nominal Air Gap (Center) | Approx. 2.7 mm (0.11”) |
| Long-Term Drift | < 0.3% |
| Static Range | ±2.0 mm (0.079”) |
| Dynamic Range | 0–1,000 μm (0–0.039”) |
Target & Environmental |
|
|---|---|
| Target Material | Ferromagnetic Steel (42CrMo4) |
| Max Surface Speed | 2,500 m/s (98,425 ips) |
| Operating Temperature | -35 to +150°C (-31 to +302°F) |
| Temperature Error | <4% / 100°K (API 670 Compliant) |
| Pressure Resistance | 10,000 hPa (145 psi) |
Physical & Electrical |
|
|---|---|
| Material | Stainless Steel Sleeve / PTFE Cable |
| Weight | Approx. 200 g (with 1m cable) |
| Sleeve Thread | M18 × 1.5 |
| Armored Cable | Included |
| Adapter Plug | Included |
| Total Cable Length | 8 m |
| Cable End Connector | LEMO |
Ordering Information |
|
|---|---|
| Sensor Type | PR6424 |
| Signal Converter | CON021 Eddy Current Signal Converter |
| Measuring Range | 4.0 mm (Standard Range) |
| Linearity Error | ≤ 1.5% |
| Total Sensor Length | 70 mm (C = Cx + 12.5 mm) |
