DO 24VDC High-Side CHARM KL3002X1-BA1 Emerson DeltaV
In stock, ready to ship
Manufacturer: Emerson
Product No.: KL3002X1-BA1
Product Type: Digital Output CHARM
Product Origin: USA
Payment: T/T
Weight: 1300g
Shipping port: Xiamen
Warranty: 12 months
Yes, we provide a 30-day money-back guarantee for all purchases.
Yes, all items come with a 12-month warranty from the date of shipment.
Product Overview
Emerson KL3002X1-BA1 is a single-channel Digital Output CHARM providing high-side 24 VDC switching for DeltaV Electronic Marshalling systems. It offers galvanic isolation, diagnostics and hot-swap capability for discrete actuation.
Key Specs
- Type: DO 24 VDC High-Side CHARM
- Output: High-side switch (sourcing)
- Current: Up to 0.5 A class
- CHARM Bus Power: 6.3 VDC at 32 mA
- Field Circuit: 24 VDC at 5 mA class
- Key position: 3C
- Operating temperature: −40 °C to +70 °C
- Diagnostics: Open load, short-circuit, over-temperature
Why Choose This
- Single-channel granularity
- High-side switching for safer field wiring
- Built-in diagnostics and isolation
- Hot-swappable in non-hazardous areas
Common Questions
- Type? High-side 24 VDC DO CHARM.
- Current? Up to 0.5 A class.
- Key? 3C.
Mounting Steps
- Install the CHARM baseplate / terminal block.
- Insert the KL3002X1-BA1 into the correct key position.
- Wire the 24 VDC field load.
- Configure the channel in DeltaV.
- Verify output status and diagnostics.
Buying Advice
- Ideal for discrete actuation with Electronic Marshalling.
- Confirm baseplate and keying compatibility.
- Useful spare for high-side DO CHARM applications.
