CANopen Master PCMCIA Card TSXCPP110 Schneider Premium
Manufacturer: Bently Nevada
Product No.: TSXCPP110
Product Type: CANopen Communication Card
Product Origin: USA
Payment: T/T
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
Yes, we provide a 30-day money-back guarantee for all purchases.
Yes, all items come with a 12-month warranty from the date of shipment.
Product Overview
Schneider Electric TSXCPP110 is a CANopen bus master PCMCIA card for Modicon Premium processors. It enables the PLC to act as a CANopen master for distributed field devices at speeds up to 1 Mbit/s.
Key Specs
- Type: CANopen bus master PCMCIA card
- Platform: Modicon Premium TSX P57
- Protocol: CANopen (DS 301 V4.02 class)
- Transmission rates: 10 kbit/s to 1 Mbit/s
- Connection: SUB-D 9 + TAP junction
- Current consumption: Approx. 60 mA at 5 V DC
- Memory type: PCMCIA Type III
Why Choose This
- Adds CANopen master capability to Premium CPUs
- Supports PDO and SDO services
- Standard PCMCIA form factor for processor slot
- Suitable for distributed I/O and drive networks
Common Questions
- Type? CANopen master PCMCIA card.
- System? Modicon Premium.
- Speed? Up to 1 Mbit/s.
Mounting Steps
- Insert the card into the processor PCMCIA slot (confirm CPU compatibility).
- Connect the CANopen bus via the SUB-D 9 interface and TAP.
- Configure baud rate and node parameters in the application software.
- Power up and verify bus status.
- Test communication with CANopen devices.
Buying Advice
- Not authorized on certain early TSX P57 153/154 processors — verify CPU model.
- One card per Premium processor typical.
- Useful spare for Premium CANopen master installations.
