Bently Nevada
Bently Nevada 3300/16-12-01-02-01-02-00 Proximity Housing Assembly
In stock, ready to ship
Manufacturer: Bently Nevada
Product No.: 3300/16-12-01-02-01-02-00
Product Type: Proximity Housing Assembly
Product Origin: USA
Payment: T/T
Weight: 1g
Shipping port: Xiamen
Warranty: 12 months
Yes, we provide a 30-day money-back guarantee for all purchases.
Yes, all items come with a 12-month warranty from the date of shipment.
Manufacturer: Bently Nevada
Product Number: 3300/16-12-01-02-01-02-00
Product Type: Proximity Housing Assembly
Country of Origin: USA
Weight: 480 g
Product Overview
The 3300/16-12-01-02-01-02-00 is an aluminum proximity probe housing assembly designed for external mounting. It includes a dome cover, threaded ports for conduit connections, a probe sleeve, O-rings, a reverse mount proximity probe, a thread seal, and optional conduit fittings and standoff adapter.
Features
-
Aluminum construction
-
Explosion-proof and CSA Type 4 rated
-
Compliant with API 670 Standard
-
Suitable for hazardous areas
-
Available with intrinsic safety certification
-
Compact design for space-restricted applications
-
Flexible mounting options
-
Enhanced environmental resistance
Technical Specifications
-
Probe: 3300 XL 8mm
-
Probe Cable Length: 0.5 meters (20 inches)
-
Standoff Adapter Length: Not included
-
Probe Penetration: 0.5 inches (12.7 mm)
-
Sleeve Length: 5.0 inches (127 mm)
-
Mounting Thread: 3/4-14 NPT
-
O-ring Option: Neoprene
-
Rear Thread Type: 1/2-14 NPT
-
Operating Temperature:
-
T5: −50°C to +40°C
-
T4: −50°C to +80°C
Additional Information
-
Long sleeves (> 304 mm / 12 inches) require additional support to reduce vibration.
-
Custom sleeve supports are available.
-
Accessories include probe support/oil seal (part number 37948-01).
