Bently Nevada 1034549-10 Vibration Monitoring Module

The Bently Nevada 1701/10 (1034549-10) is a vibration monitoring module specifically designed for machinery protection and condition monitoring systems. As part of Bently Nevada’s trusted 1701 Series, this module offers continuous vibration measurement, alarm processing, and system interface functions.

• It ensures machinery safety by detecting abnormal vibration levels, allowing early intervention to prevent equipment failures.

• Commonly used for monitoring turbines, compressors, pumps, and other rotating equipment.

Technical Specifications:

• Model Number: 1701/10

• Part Number: 1034549-10

• Power Supply:

• 24 VDC nominal (typical operating range: 18 to 30 VDC)

• Input Channels:

• 2 independent dynamic signal inputs for vibration probes

• Input Type:

• Compatible with proximity probes, accelerometers, or velocity transducers

• Frequency Response:

• 0.5 Hz to 20 kHz (depending on transducer type)

• Measurement Range:

• Configurable for 0–20 mm (displacement) or ±50 g (acceleration)

• Signal Processing:

• RMS, peak, or true peak detection with programmable filtering

• Outputs:

• 4–20 mA proportional output per channel

• Relay outputs for alarm/trip conditions

• Alarms:

• Programmable alert and danger levels

• Latching/non-latching options

• Operating Temperature:

• –20 °C to +65 °C

• Mounting:

• DIN-rail or panel-mount enclosure

• Compliance:

• Meets API 670 machinery protection standard
