Allen Bradley 1794-IF8IH Isolated Analog Input Module with HART (8-Channel)
In stock, ready to ship
Manufacturer: Allen-Bradley
Product No.: 1794-IF8IH
Product Type: Analog Input
Product Origin: Sweden
Payment: T/T
Weight: 1000g
Shipping port: Xiamen
Warranty: 12 months
Yes, we provide a 30-day money-back guarantee for all purchases.
Yes, all items come with a 12-month warranty from the date of shipment.
Allen-Bradley 1794-IF8IH
8-Channel Isolated Analog Input Module with HART
Product Overview
The 1794-IF8IH is an 8-channel isolated analog input module from the Allen-Bradley FLEX I/O family.
Technical Specifications
| Attribute | Specification |
|---|---|
| Catalog Number | 1794-IF8IH |
| Module Type | Isolated Analog Input with HART |
| Number of Channels | 8 single-ended, isolated inputs |
| Input Signal Range | 0–20 mA or 4–20 mA (user configurable) |
| Resolution | 16-bit unipolar / 15-bit + sign bipolar |
| Conversion Type | Sigma-Delta |
| Conversion Rate | Typically 10 ms (refer to update rate table) |
| Data Format | Engineering Units, % Full Scale, RAW Count |
| Isolation Voltage | 50 V continuous (field to system) |
| Power Supply | 24 VDC nominal (19.2–31.2 VDC, 5% ripple) |
| Power Consumption | 190 mA @ 24 VDC |
| Flexbus Current | 80 mA @ 5 VDC |
| Terminal Base Compatibility | 1794-TB3G or 1794-TB3GS |
| Dimensions (H × W × D) | 46 × 94 × 53 mm |
| Operating Temperature | –20°C to +55°C |
| Storage Temperature | –40°C to +85°C |
| Certifications | CE, UL, ATEX, IECEx, RoHS |
Features
- HART-enabled for remote diagnostics and device configuration
- Channel-to-channel isolation enhances signal integrity
- Pass-through messaging allows communication with HART field devices via controller or HMI
- Compatible with asset management systems using FDT/DTM technology
- Factory calibrated with support for optional field recalibration
- Compact form factor ideal for distributed and remote I/O panels
- Ideal for process control, instrumentation, and intelligent field device integration
