ABB CP-E 24/5.0 Power Supply – 24VDC 5A Industrial Unit

1. Product Summary

The ABB CP-E 24/5.0 power supply delivers stable 24 VDC output performance for demanding industrial control systems. Its switch-mode architecture supports high efficiency and consistent regulation across a broad input range. Moreover, the unit adapts automatically to 115 or 230 VAC inputs, allowing engineers to standardize designs across multiple regions. This versatility helps machine builders maintain reliable operation even under fluctuating supply conditions.

2. Functional Highlights and Key Benefits

The power supply provides a rated output current of 5 A, which ensures adequate capacity for PLCs, sensors, and motion components. In addition, its U/I output characteristic supports robust overload behavior during high inrush loads. The adjustable voltage range from 22.5 to 28.5 VDC enables precise tuning for sensitive devices requiring customized supply margins. Therefore, system integrators gain flexible power distribution options while maintaining strong protection against voltage drops. Furthermore, up to three units can be connected in parallel to increase available power, allowing scalable system growth without redesign. A dedicated redundancy module is also available for applications requiring fault-tolerant architectures.

3. Technical Specifications

Electrical Data

• Input voltage ranges: 90–132 VAC / 180–264 VAC / 210–375 VDC

• Rated input voltage: 115 / 230 VAC (auto-select)

• Output voltage: 24 VDC, adjustable 22.5–28.5 VDC

• Output current: 5 A

• Rated output power: 120 W

• Output characteristic: U/I

• Parallel connection: Up to 3 units

Mechanical Data

• Width: 63.2 mm

• Height: 123.6 mm

• Depth: 123.6 mm

• Net weight: 0.882 kg

Identification

• Product ID: 1SVR427034R0000

• EAN: 4016779669689

4. Typical Applications and Integration

This power supply supports continuous operation in automation cabinets, process equipment, and advanced machine control systems. For instance, OEMs integrate it into distributed I/O networks that require clean 24 VDC power for sensors and interfaces. Moreover, its parallel capability allows engineers to expand power capacity for high-load motion systems without switching to oversized single units. The design also suits redundancy-based control architectures used in safety-oriented or mission-critical applications.

5. Reliability and Service

ABB validates the CP-E range for long-term durability, which ensures stable performance even in thermally challenging enclosures. Furthermore, global service teams provide rapid support and documentation access, enabling efficient troubleshooting during commissioning. Therefore, maintenance teams benefit from predictable operation and consistent component availability across multiple facilities.

6. FAQ

Q1: Can the CP-E 24/5.0 be used for redundant power configurations?
Yes, the unit supports redundancy when combined with the appropriate ABB module.

Q2: Does the device handle fluctuating AC inputs?
Yes, the wide input range ensures strong performance during moderate voltage variations.

Q3: Can multiple power supplies be paralleled?
Yes, up to three units can be connected in parallel to increase output capacity.

Q4: Is the output voltage adjustable for sensitive equipment?
Yes, engineers can fine-tune the output between 22.5 and 28.5 VDC.

Q5: Which applications benefit most from this device?
Automation panels, process controllers, and motion systems benefit from its stable DC supply.
