ABB Bailey INFI 90 INBIM02 Communication Interface Module

Bailey INBIM02

Communication Interface Module for Bailey INFI 90 DCS

Product Description

The INBIM02 is a communication interface module designed for the Bailey INFI 90 Distributed Control System (DCS). It facilitates high-speed data exchange between various system nodes, enabling seamless integration and efficient signal processing. Engineered with industrial-grade durability and intelligent diagnostics, the INBIM02 ensures stable communication across complex control architectures.

Key Features

  • Reliable Data Transmission – Supports fast and stable communication between control components.

  • Robust Design – Built for continuous operation in harsh industrial environments.

  • Modular Compatibility – Fully integrates with Bailey INFI 90 DCS architecture.

  • Diagnostic Indicators – Equipped with LED status indicators for real-time operational feedback.

  • Noise Isolation – Designed to minimize electromagnetic interference for stable performance.

Technical Specifications

  • Model: INBIM02

  • System Compatibility: Bailey INFI 90 DCS

  • Communication Type: Bus Interface

  • Power Supply: 24 VDC

  • Operating Temperature: -20°C to +60°C

  • Dimensions: 160 mm × 100 mm × 50 mm

  • Weight: 1.0 kg

  • Mounting Type: DIN Rail

  • Certifications: CE, UL

Technical Details

  • Memory:

    • LIM: 2 kB RAM, 4 kB ROM

    • BIM: 32 kB RAM, 16 kB ROM

  • Power Requirements:

    • LIM: +5 VDC @ 2.0A (10W nominal)

    • ±15 VDC @ 80mA (1.2W nominal)

    • BIM: +5 VDC @ 1.0A (5W nominal)

    • +15 VDC @ 150mA (2.25W nominal)

    • -15 VDC @ 120mA (1.80W nominal)

  • System Capability: Up to 63 nodes (PCU, OIS, or NIU combinations)

  • Communication Rate: 500 kbaud, up to 800 messages/second

  • Synchronization Time: ≤100 milliseconds

  • Cable Specifications:

    • Plant Loop (Node-to-Node): max 2000 m (6561 ft)

    • LIM to TPL/IPL: max 61 m (200 ft)

  • Environmental Ratings:

    • Temperature: 0°C to 70°C (32°F to 158°F)

    • Humidity: 0–95% (up to 55°C), 0–45% (up to 70°C), non-condensing

    • Pressure: Sea level to 3 km (1.86 miles)

  • Certification: CSA certified for use in ordinary (non-hazardous) process environments
