ABB
ABB 3BSC610066R SD833 Power Supply Module
In stock, ready to ship
Manufacturer: ABB
Product No.: 3BSC610066R SD833
Product Type: Power Supply Module
Product Origin: Sweden
Payment: T/T
Weight: 520g
Shipping port: Xiamen
Warranty: 12 months
Yes, we provide a 30-day money-back guarantee for all purchases.
Yes, all items come with a 12-month warranty from the date of shipment.
The ABB 3BSC610066R1 (type designation SD833) is a high-performance, switch-mode power supply unit designed for industrial automation. It plays a critical role in the ABB Ability™ 800xA, Symphony Plus, and Advant DCS systems, primarily providing stabilized 24V DC power to controllers and I/O modules.
Key Technical Specifications
| Feature | Specification |
|---|---|
| Output Voltage | 24 V DC |
| Output Current | 10 A (Rated) / 12 A (Max at ambient < 45°C) |
| Output Power | 240 W |
| Input Voltage | 100–120 V / 200–240 V AC (Auto-select) |
| Efficiency | ~91% |
| Dimensions | 124 mm (H) x 60 mm (W) x 117 mm (D) |
| Weight | 0.8 kg (1.76 lbs) |
Core Functional Features
-
Soft Start Capability
Prevents tripping of mains fuses or earth-fault circuit breakers by limiting inrush current during startup. -
Redundancy Ready
Can be used in redundant configurations by connecting it to a diode voting unit, such as the SS823 or SS832. -
Advanced Protection
-
Over-voltage protection (OVP < 39 V).
-
Current-limiting short-circuit protection (14–18 A).
-
Compliance
Meets EN 50178 and UL 508 safety standards, suitable for SELV (Safety Extra Low Voltage) and PELV (Protective Extra Low Voltage) applications.
