ABB 3BDH00011R1 SA801F Power Supply Module

The ABB 3BDH00011R1 SA801F Power Supply Module is a high-performance industrial power supply solution designed to ensure reliable energy distribution for ABB automation systems. Engineered for maximum reliability, the SA801F module offers stable and continuous power, supporting a variety of industrial applications. With its robust construction and energy-efficient performance, it is ideal for powering controllers, modules, and other components within your automation infrastructure.

Functional Highlights / Key Benefits

• Stable Power Supply: The SA801F module ensures consistent and reliable power for ABB automation systems, reducing the risk of power disruptions.

• Wide Input Voltage Range: With its broad input voltage range, the SA801F offers flexibility, making it suitable for various industrial applications across different regions.

• Energy Efficient: Designed to operate with high efficiency, this power supply module minimizes energy consumption and supports sustainable practices.

• Compact and Durable: Its robust design and compact size allow the SA801F to fit seamlessly into existing automation setups, even in space-constrained environments.

• Low Maintenance: Built for longevity, the SA801F requires minimal upkeep, contributing to reduced operational costs and maintenance efforts.

Technical Specifications

• Product Type: Power Supply Module

• Model: SA801F

• Part Number: 3BDH00011R1

• Output Voltage: 24 VDC

• Input Voltage Range: 85-264 VAC

• Operating Temperature: -10°C to +60°C

• Dimensions:

• Length: 150 mm

• Width: 85 mm

• Height: 120 mm

• Net Weight: 0.8 kg

• Efficiency: > 90%

• Cooling: Natural convection

• Compliance: CE Certified

• RoHS Compliance: Yes

• WEEE Category: 5 (Small Equipment, No External Dimension More Than 50 cm)

FAQ

1. What is the output voltage of the ABB SA801F Power Supply Module?

• The ABB SA801F provides a stable 24 VDC output to power ABB automation systems.

2. What is the input voltage range for the SA801F?

• The SA801F supports an input voltage range of 85-264 VAC, providing flexibility in various regions and applications.

3. Is the ABB 3BDH00011R1 SA801F Power Supply Module energy-efficient?

• Yes, the SA801F operates with an efficiency greater than 90%, ensuring low energy consumption.
