8pt Relay Output BMXDRA0815 Schneider X80 24-240VAC
Manufacturer: Schneider
Product No.: BMXDRA0815
Product Type: Discrete Output Module
Product Origin: USA
Payment: T/T
Weight: 1600g
Shipping port: Xiamen
Warranty: 12 months
Yes, we provide a 30-day money-back guarantee for all purchases.
Yes, all items come with a 12-month warranty from the date of shipment.
Product Overview
Schneider Electric BMXDRA0815 is an 8-channel isolated relay discrete output module for Modicon X80. It provides NO Type A relay contacts rated 24–240 V AC or 24–125 V DC for switching contactors, solenoids and mixed AC/DC loads.
Key Specs
- Platform: Modicon X80
- Channels: 8 NO isolated relay outputs
- Voltage: 24–240 V AC (19–264 V); 24–125 V DC (5–150 V)
- Current: Approx. 3 A conventional free-air thermal
- Connection: 20-pin removable terminal block
- Response: ≤ 10 ms activation / ≤ 13 ms deactivation class
- Power dissipation: Approx. 3.6 W
- Compatibility: Modicon M340 / M580
Why Choose This
- Isolated relays for mixed AC and DC loads
- Wide voltage range for global installations
- Channel status LEDs for diagnostics
- Standard X80 form factor
Common Questions
- Points? 8 NO relay outputs.
- Voltage? 24–240 V AC / 24–125 V DC.
- Platform? Modicon X80.
Mounting Steps
- Install the module in an X80 rack slot.
- Fit a 20-pin terminal block and wire loads with external protection.
- Configure output channels in the engineering software.
- Power up and verify channel status LEDs.
- Test load switching under operating conditions.
Buying Advice
- Observe maximum current and inductive load suppression requirements.
- Select for mixed AC/DC discrete control where relays are preferred.
- Useful spare for X80 relay output positions.
