Emerson
8ch Isolated Discrete Input 8109-DI-DC-01 MTL
In stock, ready to ship
Manufacturer: Emerson
Product No.: 8109-DI-DC-01
Product Type: Discrete Input Module
Product Origin: USA
Payment: T/T
Weight: 1400g
Shipping port: Xiamen
Warranty: 12 months
Yes, we provide a 30-day money-back guarantee for all purchases.
Yes, all items come with a 12-month warranty from the date of shipment.
Product Overview
The MTL 8109-DI-DC-01 is an 8-channel discrete input module with isolated 24 V DC sinking inputs. It supports user-definable thresholds, pulse counting and selectable filtering for PAC8000 systems.
Key Specs
- Channels: 8 discrete inputs
- Input type: 24 V DC isolated, sinking
- ON voltage: >11 V DC / OFF: <3.2 V DC
- Wetting current: Approx. 6.3 mA @ 24 V DC
- Pulse counting: Up to 200 Hz class
- Isolation: Channel isolation supported
- System: MTL PAC8000
Why Choose This
- Isolated discrete inputs for noise immunity
- Configurable thresholds and filtering
- Pulse counting capability
- Compact 8-channel design
Common Questions
- Channels? 8 DI isolated.
- Voltage? 24 V DC class.
- System? PAC8000.
Mounting Steps
- Install the module on the PAC8000 carrier.
- Wire the 24 V DC discrete field devices.
- Configure filter, latch and pulse options.
- Power up and verify input status.
- Test switching and pulse counting functions.
Buying Advice
- Choose when isolated discrete inputs are required.
- Confirm key code and carrier compatibility.
- Useful spare for PAC8000 isolated DI positions.
