8ch High-Level Analog Input TC-FIAH81 Honeywell
In stock, ready to ship
Manufacturer: Honeywell
Product No.: TC-FIAH81
Product Type: High-Level Analog Input Module
Product Origin: USA
Payment: T/T
Weight: 1100g
Shipping port: Xiamen
Warranty: 12 months
Yes, we provide a 30-day money-back guarantee for all purchases.
Yes, all items come with a 12-month warranty from the date of shipment.
Product Overview
The Honeywell TC-FIAH81 is an 8-channel high-level analog input module. It accepts voltage (±10 V / 0–10 V) or current (4–20 mA / 0–20 mA) signals for precise process measurement in C200 systems.
Key Specs
- Channels: 8 single-ended
- Voltage range: ±10 V or 0–10 V
- Current range: 4–20 mA or 0–20 mA
- Resolution: 12-bit class
- Accuracy: ±0.20% full scale @ 25 °C
- Isolation: User-to-system (850 V DC)
- Power dissipation: Max 3 W
Why Choose This
- Flexible voltage or current input per channel
- Suitable for high-level process signals
- Compact design for C200 / Flexbus systems
- Overload protection included
Common Questions
- How many channels? 8.
- Input types? Voltage or current (configurable).
- Isolation? User-to-system isolation.
Mounting Steps
- Insert the module into the I/O chassis.
- Connect field analog signals to the terminal block.
- Configure each channel for voltage or current.
- Power up and verify readings.
- Scale and calibrate as required in the system.
Buying Advice
- Select for high-level analog signal acquisition.
- Confirm signal type matches field transmitters.
- Useful spare for C200 analog input requirements.
