40-Way Cord Set BMXFCW303 Schneider 3m Flying Leads
Manufacturer: Schneider
Product No.: BMXFCW303
Product Type: Preformed Cord Set
Product Origin: USA
Payment: T/T
Weight: 1500g
Shipping port: Xiamen
Warranty: 12 months
Yes, we provide a 30-day money-back guarantee for all purchases.
Yes, all items come with a 12-month warranty from the date of shipment.
Product Overview
Schneider Electric BMXFCW303 is a 3 m preformed cord set with a 40-way connector and colour-coded flying leads for Modicon X80 / M340 I/O modules. It provides ready-to-install wiring for 32-channel discrete modules.
Key Specs
- Type: Preformed cord set
- Connector: 1× 40-way female
- Termination: 40 colour-coded flying leads (DIN 47100)
- Length: 3 m
- Wire: AWG 22 (0.324 mm²)
- Platform: Modicon X80 / M340
Why Choose This
- Eliminates custom cable assembly
- Colour-coded leads reduce wiring errors
- Fits 32-channel modules (two cords for 64-channel)
- Standard accessory for high-density discrete I/O
Common Questions
- Length? 3 m.
- Connector? 40-way.
- Use? X80/M340 40-way I/O modules.
Mounting Steps
- Plug the 40-way connector onto the I/O module.
- Route both cable sheaths to the field terminals.
- Terminate colour-coded leads per the wiring diagram.
- Secure strain relief and verify continuity.
- Power up and check channel status.
Buying Advice
- Match to 32-channel modules; order two for 64-channel modules.
- Choose 3 m, 5 m or 10 m by cabinet distance.
- Useful accessory for rapid discrete I/O wiring.
