The Bently Nevada 3500/22M-01-01-00 Standard Transient Data Interface (TDI) Module, comprising part numbers 288055-01 and 146031-01, is an essential component for the Bently Nevada 3500 Series machinery monitoring system. This TDI module enables high-performance data acquisition and real-time communication for industrial machinery monitoring, offering advanced transient data analysis for predictive maintenance.

Key Features:

• Data Acquisition: The 3500/22M-01-01-00 module continuously collects both steady-state and transient dynamic (waveform) data from Bently Nevada 3500 monitoring modules. It captures critical machine performance data, ensuring early detection of issues before they lead to failures. Standard static data capture is always enabled, with the option for dynamic data collection via a Channel Enabling Disk.

• Communication Interface: The module includes a 10Base-T/100Base-TX Ethernet I/O interface (via part number 146031-01), enabling seamless communication between the monitoring system and host software (such as Bently Nevada’s System 1) over a network. This ensures quick and efficient data transfer for analysis, diagnostics, and long-term storage.

• System Integration: Designed to fit within a single slot (typically Slot 1) of the 3500 rack, the TDI module works in conjunction with M-series monitors like the 3500/40M and 3500/42M, integrating effortlessly into your machinery monitoring system for enhanced performance.

• Rack-Level Functions: While not directly involved in the critical monitoring path, the TDI provides common functions across the entire rack, contributing to the overall efficiency and reliability of the 3500 monitoring system.

Application:

The 3500/22M-01-01-00 TDI module is ideal for industries where machinery reliability is crucial, such as power generation, oil & gas, and manufacturing. By offering real-time data collection and advanced diagnostics capabilities, it helps prevent unexpected downtime, extends equipment life, and optimizes operational performance.

Components Included:

• 288055-01: Standard Transient Data Interface Module

• 146031-01: Ethernet I/O Module (10Base-T/100Base-TX) for network communication

This TDI module is a vital tool for enhancing machinery monitoring capabilities, providing the data and connectivity needed to keep industrial equipment running at peak performance.

-----------------------------------------------------------------------------------------------
